DISTRICTCON Year 1

Pin Definitions

// Display
#define TFT_DC 0
#define TFT_CS 5
#define TFT_SDA 3
#define TFT_SCL 2
#define TFT_RST 4
#define TFT_BL 1

// Button pins
#define BTN_RIGHT 20
#define BTN_DOWN 21
#define BTN_UP 22
#define BTN_LEFT 23
#define BTN_A 7
#define BTN_B 6

// Hardware pins
#define PIN_IR_RECV 16
#define PIN_SNIFFY 19
#define PIN_LEDS 24
#define PIN_MIC A1
#define PIN_DIVIDE_1 28
#define PIN_DIVIDE_2 29

// SAO Pins
#define SAO_I2C_SDA 8
#define SAO_I2C_SCL 9
#define SAO_GPIO1 10
#define SAO_GPIO2 11
